Global Drive Control | L-force Controller as Gateway
Controller as gateway
Controller as gateway via CAN
4.2 Controller as gateway via CAN
4.2.1 Setting the communication path

Tip!
Before working on the communication parameters, switch to the offline mode. To
activate the offline mode, press the F4 button:
To use the L-force Controller as gateway, you must select the suitable communication dri-
ver: Options

Communication.
4.2.2 Selecting the communication driver
Select Controller Gateway -> CAN from the list of drivers available:
 Access the Gateway -> CAN dialog window via the Parameter button.
– Set communication parameters:
 To set the communication parameters, you must enter the following configuration da-
ta:
Information Function
IP address IP address of the L-force Controller which serves as gateway for communica-
tion
