Operation
Download
EDKMZ2221IB DE/EN/FR 6.0
37
l
H1_Bedienung−Download
Carrying out a download
1. Insert the memory card in the card module (
^ 33).
2. Plug the card module onto the AIF interface of the basic device. (
The 7−segment display
0
indicates that the card module is ready for operation.
3. Press key T3 repeatedly until the 7−segment display indicates the program memory
location the data of which are to be transferred to the basic device.
The download can only be carried out if both LEDs are lit:
– Yellow LED is lit: Data are available on the program memory location selected.
– Green LED is lit: The data set corresponds to the basic device (green LED).
4. Press key T1 to start the download.
During the download, a rotating/stationary bar is shown on the 7−segment display.
After the download has been carried out successfully, the program memory location
selected is shown again.
In order to restart the application program on the basic device after a download, switch
the basic device off and on again.
Download failed
If the download fails, the letter
E
and an error code (
1
to
8
or
F
)) are alternately indicated on
the 7−segment display.
Information on the error codes can be found in the chapter "Troubleshooting and fault
elimination" (
^ 38).
By pressing key T3 the error code can be reset; the selected program memory location is then
indicated again.
