2 Technical data
General data and operating conditions
EDKMZ2221IB DE/EN/FR 6.0
28
l
H1_Daten−Maße_mm
2 Technical data
General data and operating conditions
General data
Conformity and approval
Approbation
UL UL 508C Industrial Control Equipment
File No. E132659
for USA and Canada
Protection of persons and devices
Type of protection EN 60529 IP20
Operating conditions
Ambient conditions
Climate
Storage IEC/EN 60721−3−1 1K3 (−20 to +65 °C)
Transport IEC/EN 60721−3−2 2K3 (−20 to +65 °C)
Operation IEC/EN 60721−3−3 3K3 (0 to +50 °C)
Humidity class F without condensation (average relative humidity
85%)
Position
Permissible
mounting position Plugged on the AIF interface of one of the basic devices
listed under "Range of application"
Electrical data
Area Values
DC voltage supply Internal, via the basic device
Insulation voltage to
reference earth/PE 50 V AC
