3 Installation
Plugging on and removing the card module
)
Note!
ƒ The card module may be plugged on or removed during the basic device is
operated, but not during a running data transmission, as data losses may
occur!
ƒ Always secure the card module on the basic device using the fixing screw,
as otherwise no reliable contact is ensured and data losses may occur.
Mounting
AIF
‚
AIF
8
Car d M odu le l Display is blinking
Anzeige blinkt
E1 Stop drive (T1 for 3s)
E2 Check card
E3 Check drive
E4 Retr y (T1 or T2)
E5 Technolog y d rive needed
E6 Drive not supported
E7 Prog. is defect EF Forma t card (T3)
E1 Antrieb stoppen (T1 für 3s)
E2 Karte prüfen
E3 Antrieb prüfen
E4 Wiederholen (T1 bzw . T2)
E5 Technologieantrieb
nötig
E6 Antrieb nicht unterstützt
E7 Prog. defekt
EF Karte forma tieren (T3)
Prog.
Card > Drive Karte > A ntrieb
Prog. 0…9, A…F
Drive > Card Antrieb > K arte
used belegt
matched passt
T1 T2
T3 222 1
Smart Media-Card / Karte SD-Card / Karte

2221_004
