Mechanical installation
Mounting with fixing rails (standard)
4

18 EDBCSXKXXX EN 1.0
4.2 Mounting with fixing rails (standard)
Type ECSEKxxx
For standard mounting into the control cabinet the capacitor module types ECSEKxxx
must be used. The accessories required for mounting are included in the scope of supply.
Dimensions
h h
e a
g
d b
g
a
d b
g g
³
50
mm
³
50
mm
ECSXK005
Fig.4-1 Dimensions for standard mounting with fixing rails, ECSEKxxx type
Capacitor modules Dimensions [mm]
Type Size O B D E g h
ECSEK001 1 88.5
276 260 176
6.5
10
ECSEK002 2 132
276 260 176
6.5
(M6)
10
Mounting
For mounting the capacitor module ECSEKxxx proceed as follows:
1. Prepare the fixing holes (see drawing)
2. Take the fixing rails from the accessory kit in the cardboard box.
3. Push the rails into the slots of the heatsink:
– From above: push in the long side.
– From below: push in the short side.
4. Fix the capacitor module onto the mounting plate.
