Technical data
General data/operating conditions
3
15
EDBCSXKXXX EN 1.0
3
Technical data
3.1
General data/operating conditions
Standards and operating conditions
Conformity
CE
Low-Voltage Directive (73/23/EWG)
Approvals
UL 508C
Power Conversion Equipment
Underwriter Laboratories (File No. E132659)
for USA and Canada
Vibration resistance
Accelerational stability up to 0.7 g (Germanischer Lloyd, general conditions)
Climatic conditions
Class 3K3 to EN 50178 (without condensation, relative humidity 30 ... 95 %)
Degree of pollution
VDE 0110 part 2 pollution degree 2
Packaging (DIN 4180)
Delivery packing
Permissible
Transport
-25 ... +70 °C
temperature range
Storage
-25 ... +55 °C
Operation
0 ... +55 °C
reduce the rated AC current by 2 %/°C above +40°C
Permissible installation height
0 ... 4000 m amsl
reduce rated AC current by 5%/1000 m above 1000 m amsl
Installation
Installation into control cabinet
Mounting position
Vertically suspended
Free space
Above/below
≥
50 mm
p
To the sides
Side-by-side mounting without any clearance
General electrical data
EMC
Compliance with EN 61800-3
Noise emission
Compliance with limit value class A to EN 55011
(achieved with application-specific collective filter)
Noise immunity
Requirements to EN 61800-3
y
Requirements
Standard
Severity
ESD
1)
EN 61000-4-2
3, i. e.
z
8 kV with air discharge
z
6 kV with contact discharge
High frequency in cables
EN 61000-4-6
10 V; 0.15 ... 80 MHz
RF interference (enclosure)
EN 61000-4-3
3, i. e. 10 V/m;
80 ... 1000 MHz
Burst
EN 61000-4-4
3/4, i. e. 2 kV/5 kHz
Surge (on mains cable)
EN 61000-4-5
3, i. e. 1.2/50 µs
z
1 kV phase-phase
z
2 kV phase PE
Insulation resistance
Overvoltage category III to VDE 0110
Discharge current against PE (to EN 50178)
> 3.5 mA AC for operation with corresponding controllers
Enclosure
z
IP20 for standard mounting
z
IP20 for mounting in cold-plate technique
z
IP20 for mounting in push-through technique; IP54 on the heatsink side
Protective insulation of control circuits
Safe disconnection from supply: Double/reinforced insulation to EN 50178;
Rated insulation voltage 300 V x √2
1)
Noise immunity in the above-mentioned severities must be guaranteed through the control cabinet! The user must
check the compliance with the severities!
