Commissioning
L
72 EDBEPM-H520 DE/EN/FR 4.0
4.1.1 Touch screen calibration
! It is possible that you will be asked to calibrate the touch screen when you switch on the
module for the first time.
! The calibration defines the positions of the sensitive fields on the display.
! ! ! !
Note!
!
Ensure careful calibration of the display.
! If the calibration is faulty or inexact, switch off the keypad and restart it before
you repeat the calibration.
What to do
1. Switch on the supply voltage for the keypad.
H520 TRANSFER PAGE
Touch screen BOOT check:
Please touch bottom left
0
The unit is initialized.
H520 TRANSFER PAGE
Touch screen BOOT check:
Please touch bottom left
0
2. Exactly touch field & .
H520 TRANSFER PAGE
Touch screen BOOT check:
Please touch bottom left
0
