Installation
L
67 EDBEPM-H520 DE/EN/FR 4.0
3.2.3 Flash module mounting
Flash module 8 MB (back-up)
! Use this card to store and archive your application-specific configuration for a project. (% 90)
!
The card can be fitted in any keypad of the same type to transfer project data to this keypad.
! The 8 MB flash module can be ordered from Lenze under order no. EPZ-H221.
Flash module 4 MB (memory extension)
! The flash module extends the RAM of the keypad by 4 MB.
!
After the memory card has been assembled, 4 MB are additionally available. Further
configuration is not necessary. (% 90)
!
The 4 MB flash module can be ordered from Lenze under order no. EPZ-H220.
$ $ $ $
Stop!
! Disconnect the keypad from its voltage supply before you start working on it to
avoid damage of electrical equipment.
! Keypad and flash module include electrostatical components which can be
damaged if not handled properly.
