Communication manual 8400 motec PROFIBUS
Parameter reference
Parameters relevant for PROFIBUS communication
84
L
EDS84DMOTPBUS EN 3.0 - 11/2011
C13862
C13863
C13864
C13865
Parameter | Name:
C13862 | Bus counter
Data type: UNSIGNED_16
Index: 10713
d
= 29D9
h
When the maximum count value of 65535 is reached, the counter starts again with 0.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C13862/1 Data cycles per second
C13862/2 Total data cycles
C13862/3 Total parameterisation events
C13862/4 Total configuration events
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13863 | Baud rate
Data type: UNSIGNED_8
Index: 10712
d
= 29D8
h
Display of the baud rate
Selection list
(read only)
0 12.00 Mbps
1 6.00 Mbps
2 3.00 Mbps
3 1.50 Mbps
4 500.00 kbps
5 187.50 kbps
6 93.75 kbps
7 45.45 kbps
8 19.20 kbps
9 9.60 kbps
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13864 | Active station address
Data type: UNSIGNED_8
Index: 10711
d
= 29D7
h
Display of the active station address
Setting the station address ( 31)
Display area (min. value | unit | max. value)
0 255
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13865 | Display: Most recent PRM data
Data type: OCTET_STRING
Index: 10710
d
= 29D6
h
Display of the last parameter data sent by the PROFIBUS master with the "Set-Prm" telegram (ASCII string with 24
characters)
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
