Communication manual 8400 motec PROFIBUS
Parameter reference
Parameters relevant for PROFIBUS communication
82
L
EDS84DMOTPBUS EN 3.0 - 11/2011
13.2 Parameters relevant for PROFIBUS communication
This chapter lists the PROFIBUS parameters of the communication unit in numerically
ascending order.
C13850
C13851
C13852
Parameter | Name:
C13850 | All words to master
Data type: UNSIGNED_16
Index: 10725
d
= 29E5
h
Display of the process data words transferred from the communication unit to the PROFIBUS master.
In the subcodes 1 ... 8, all process data words to the master are displayed. However, only the configured process data
words are valid.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C13850/1 Word 1 to master
... ...
C13850/8 Word 8 to master
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13851 | All words from master
Data type: UNSIGNED_16
Index: 10724
d
= 29E4
h
Display of the process data words transferred from the PROFIBUS master to the communication unit.
In the subcodes 1 ... 8, all process data words from the master are displayed. However, only the configured process
data words are valid.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C13851/1 Word 1 from master
... ...
C13851/8 Word 8 from master
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13852 | All words to standard device
Data type: UNSIGNED_16
Index: 10723
d
= 29E3
h
Display of the process data words 1 ... 8 transferred from the communication unit to the drive unit.
In the subcodes 1 ... 8, all process data words of the communication unit are displayed.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C13852/1 Word 1 to drive unit
... ...
C13852/8 Word 8 to drive unit
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
