Installation

Mounting steps

Panel PC EL 2800 / EL 2850 / EL 5800 / EL 5820 / EL 5850 / EL 5870 / EL 9800

4

l

35

MA_ELx8xx DE/EN/FR/ES/IT 2.0

Installation in 19" mounting racks (only EL 5820, EL 5850, and EL 5870)
How to perform the installation:ounting rack installation"#
1. Remove the set screws from the back of the front frame.
2. Drill through the blind holes at the back of the front frame using a 6.5

mm drill.

3. Place the device in the 19" mounting rack and screw it.
