Leica M-series User Manual 50
The intensity of the illuminator can be
adjusted in 10 increments.
The Leica LED3000 NVI™ can also be
controlled via the Leica Application Suite
(LAS) or the Leica SmartTouch.
The supported working distance is
between 50 mm and 150 mm.
Use
• The light of the Leica LED3000 NVI™ can
be very bright. Therefore, always switch
on the illuminator before you look through the
eyepieces!
1. Switch on the illuminator by briefly press-
ing the (ON/OFF) button.
The green LED on the upper left corner now
lights up.
2. Adjust the brightness by briefly pressing
the or buttons.
3. Switch off the illuminator by briefly press-
ing the button.
Leica LED3000 NVI™ (Near Vertical Illumination)
