Page 9
9
Measuring – User Manual
1. Measuring pitch
12mm : 120
Stage micrometer
with 0.1mm
graduation
Examples
Calibrating
7.8mm on the stage micrometer (X)
120 intervals on the eyepiece graticule (Y)
7.8
120
mm = 0.065mm calibration value
Measuring
Intervals on the eyepiece graticule: 112
Result:
112 intervals
× 0.065mm = 7.3mm length of
measurement
distance
x
0
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
10
y
0
1
2
5
3
6
7
8
9
10
12
11
4
