16 Instructions for Use V1.3 RevC – 11/2012
4.3 Specifications
4. Instrument Characteristics
General data
Approvals: The instrument-specific approval marks are on the side of the
instrument next to the type plate.
Nominal voltage (+/- 10 %): 100-120/220-240 V AC
Nominal frequency: 50/60 Hz
Power fuses: 2x T 1.25 A L250 V
Nominal power: 10.5 VA
Relative humidity: 20 to 80 %, non-condensing
Operating temperature range: +18 °C to +40 °C
Operating temperatures:
+55 °C to 70 °C
Transport temperature range: -29 °C to 50 °C
IEC 1010 classification:
Protection class 1
Pollution degree 2
Overvoltage category II
Operating elevation: maximum of 2000 m above sea level
A-weighted noise level: < 70 dB (A)
IP protection class (IEC 60529): IP20
Dimensions and weight
Dimensions (W x H x D):
130 x 110 x 180 mm
Empty weight (unpacked): approx. 1.5 kg
Programmable parameters in the display
Temperature ranges displayed in °C or °F
