Klein Tools Harnesses - Manual (Page 21)

For Fall-Arrest and Retrieval Use Only
■ Harness must be worn so that the fall-arrest
D-ring is centered in back.
■ Attach retrieval V-sling connecting devices that meet
OSHA standards only to the shoulder D-rings. Shoul-
der D-rings are NOT for fall-arrest.
■ Attach fall-arrest connecting devices that
meet OSHA standards only to the rear fall-arrest
D-ring.
■
Fall-arrest anchorage must support a
minimum of 5,000 lbs. (22.2kN) per attached
worker and be independent of worker support.
■ To use the retrieval function of this harness, attach
the two locking snap hooks of the V-sling only to the
shoulder strap D-rings. Attach rope thimble eye of V-sling
only to a retrieval device meeting OSHA standards.
C2ad 1
592
Read
Other
Side
Read
Next
Tag
W
ARNINGS
W
ARNINGS
■ OSHA requires that impact force in a fall NOT
exceed an 1,800 lb. (8kN) limit with a harness.
At a given weight, the longer the free fall, the
greater the resulting impact force. Therefore,
minimize slack in fall-arrest connecting device or
use deceleration unit to stay under 1,800 lbs.
(8kN).
Read
Next
Tag
W
ARNINGS
■ Retrieval anchorage must support at least
twice the potential impact load of an employee’s
fall or 3,000 lbs. (13.3kN), whichever is greater.
■ Rig to avoid contact with structures below
in the event of a fall. The free-fall distance
must not exceed 6 ft. (1.8m). If using a deceler-
ation unit, add 3-1/2 ft. (1m) to the free-fall distance
to allow for unit extension.
■
For fall-arrest, always keep anchorage at or above
shoulder height to minimize fall distance.
W
ARNINGS
C2ad 2.
592
Read
Other
Side
Specific Tags for Fall Arrest/Suspension /
Bosun’s Chair/ Harness
87044
■ For fall-arrest, always keep anchorage at or
above shoulder height to minimize fall distance.
■ Fall-arrest anchorage must support a mini-
mum of 5,000 lbs. (22.2kN) per attached worker
and be independent of worker support.
■ Suspension anchorage must support at
least twice the potential impact load of an employee’s fall
or 3,000 lbs. (13.3kN), whichever is greater.
■ Rig to avoid contact with structures below in the
event of a fall. The free-fall distance must not exceed 6 ft.
(1.8m). If using a deceleration unit, add 3-1/2 ft. (1m) to
the free-fall distance to allow for unit extension.
C2ac 1
592
Read
Other
Side
Read
Next
Tag
W
ARNINGS
W
ARNINGS
For Fall-Arrest and Suspension Use Only
■ Attach suspension connecting devices that
meet OSHA standards only to the top front D-ring on
Bosun’s Chair harness.
■ Attach fall-arrest connecting devices that meet
OSHA standards only to the rear fall-arrest D-ring.
■ Harness must be worn so that the fall-arrest D-ring
is centered in back.
W
ARNINGS
■ Rig to avoid contact with structures below in
the event of a fall. The free-fall distance must
not exceed 6 ft. (1.8m). If using a deceleration
unit, add 3-1/2 ft. (1m) to the free-fall distance to
allow for unit extension.
■ OSHA requires that impact force in a fall NOT
exceed an 1,800 lbs. (8kN) limit with a harness. At a
given weight, the longer the free fall the greater the
resulting impact force. Therefore, minimize slack in
fall-arrest connecting device or use deceleration unit
to stay under 1,800 lbs. (8kN).
C2ac2 2.
592
Read
Next
Tag
Specific Tags for Fall Arrest/Retrieval
Harnesses
87090, 87091, 87092, 87093, 87840, 87841, 87842
Klein Harness Warning Tags
(continued)
Klein permanently attaches highly durable warning
and instruction tags and/or labels to its harnesses. In
the event any of these tags and/or labels become
unattached, lost, or damaged, contact the Klein Tools Sales Department, toll-free at 1-800-553-4676 for
information on how to have the tags and/or labels
replaced free of charge.
21
