JUMO 902910 CANtrans T RTD Temperature Probe with CANopen Output Data Sheet - Manual

2010-06-11/00418901
Data sheet 90.2910 Page 1/4
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14,
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone: +49 661 6003-0
Fax: +49 661 6003-607
E-mail: [email protected]
Internet: www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow - Essex CM20 2DY, UK
Phone: +44 1279 63 55 33
Fax:
+44 1279 63 52 62
E-mail: [email protected]
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
8 Technology Boulevard
Canastota, NY 13032, USA
Phone:
315-697-JUMO
1-800-554-JUMO
Fax: 315-697-5867
E-mail: [email protected]
Internet: www.jumo.us
JUMO CANtrans T
RTD temperature probe
with CANopen output
■ For temperatures from -50 to +450°C
■ Available as single or double RTD temperature probes
■ Vibration-proof design
■ Limit value monitoring
■ Configuration via standard CANopen software tools
RTD temperature probes are preferentially used for measuring temperatures in liquids and gas-
es. A key feature is the reliable sealing of this installation type for vacuum and overpressure.
Areas of application are, amongst others, in medical technology, mechanical engineering, drive
technology, utility vehicles, and railroad systems.
The measuring insert is equipped with a Pt 1000 temperature sensor per DIN EN 60 751, Class
B, as a standard. The measured temperature value is digitized, linearized and provided via the
serial bus protocol CANopen for further processing (CAN slave). A large number of useful addi-
tional functions are realized via the DS 404 device profile. All settings are possible via standard
CANopen software tools.
Also available, a pressure transducer with CANopen output, please refer to data sheet 40.2055
Technical Data
Connection Round plug M12x1, 5-pin per IEC 60 947-5-2
Process connection Threaded, stainless steel 1.4571
Sheath stainless steel 1.4571
Measuring insert Pt 1000 temperature sensor per DIN EN 60 751, Class B, two-wire circuit
Protection class IP67, per DIN EN 60 529, with connection plug screwed on
Response time t
0,9
= 12s, in water 0.2m/s
