2011-11-08/00402234
Data Sheet 608425
Page 6/6
Order details
Contact dial thermometers, Class 1, Type 608425
Special versions on request !
(7)
Diameter of process connection (PA)
1
X
X
0
6
diameter
0
6 mm
X
X
0
8
diameter
0
8 mm
X
X
100
diameter 10 mm
X
X
140
diameter 14 mm (only SH05)
(8)
Thread for process connection (PA)
1
X
X
000
no thread (with TF01, TF05 and TF11)
X
X
103
thread G 3/8
X
X
104
thread G 1/2
X
X
105
thread G 3/4
(9)
Process connection (PA) material
1
X
X
26
stainless steel (CrNi, 1.4571)
X
X
97
stainless steel (CrNi, 1.4571)-TF / brass (CuZn)-TA, SH
(10)
Fitting length of process connection (PA)
1
(dimension "EL" or "S")
X
X
0
0
minimum fitting length TF 11 (active probe dimension)
X
X
0
50
0
50 mm
X
X
100
100 mm
X
X
150
150 mm
X
X
200
200 mm
X
X
. . .
special length (specify in plain text, steps of 50 mm)
(11)
Switching output (SA)
X
X
01
With rising temperature: contact 1 opens (2)
3
X
X
02
With rising temperature: contact 1 closes (1)
3
X
X
03
With rising temperature: contact 1 opens and
contact 2 closes (21)
3
X
X
04
With rising temperature: contact 1 and
contact 2 close (11)
3
X
X
05
With rising temperature: contact 1 opens and
contact 2 opens (22)
3
X
10
With rising temperature: contact 1 opens and
contact 2 closes (with separate circuit) (21)
3
X
11
With rising temperature: contact 1 and contact 2 close
(with separate circuits) (11)
3
X
X
30
With rising temperature:
flag moves in, break action (2)
3
X
X
31
With rising temperature:
flag moves out, make action (1)
3
(12)
Extra codes (TZ)
X
X
000
no extra code
X
X
442
electromechanical magnetic snap-action contact
X
509
setpoint adjustment with key
X
X
522
customized scale
Order code
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
608425
/
. . . .
-
. . .
-
. .
-
. . . .
-
. . .
-
. .
-
. . .
-
. .
-
. . .
-
. . .
/
. . .
,
. . .
Order example
608425
/
2010
-
818
-
04
-
2000
-
750
-
8
-
000
-
26
-
100
-
01
/
000
4
,
. . .
1
for description and features, see Data Sheet 608730
2
screw-in spigot to DIN 3852 Form A
3
figures in brackets ( . . ) correspond to the designation of the switching function code as per DIN 16196
4
list extra codes in sequence, separated by a comma
