Data Sheet 602010 Page 6/7
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone: +49 661 6003-0
Fax: +49 661 6003-607
E-mail: [email protected]
Internet: www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
E-mail: [email protected]
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax: 315-437-5860
E-mail: [email protected]
Internet: www.jumousa.com
Order details
Panel-mounted thermostats, ETH series
Order code (1) Basic type
602010 Panel-mounted thermostat, ETH series
(2) Basic type extensions
20 ETH-20 safety temperature monitor STW With capillary
70 ETH-70 safety temperature limiter STB With capillary
(3) Control range / limit value range °C
052 +30 to +110
066 +60 to +130
043 +20 to +150
063 +50 to +250
064 +50 to +300
045 +20 to +400
046 +20 to +500
(4) Switching differential
00 Without switching differential (ETHf-70 STB)
20 2 % of the scale range
50 5 % of the scale range
70 7 % of the scale range
90 9 % of the scale range
(5) Capillary length
1000 1000 mm
2000 2000 mm
3000 3000 mm
4000 4000 mm
5000 5000 mm
.... (Special length, specifications in plain text)
(6) Capillary material
40 Cu (copper)
20 CrNi (stainless steel)
(7) Process connection For different connection
types and thermowells
refer to data sheet
606710.
10 Plain cylindrical probe
20 Screw-in thermowell
(8) Thread of process connection
00 Without thread (process connection 10)
13 External thread G 1/2
(9) Material of process connection
00 Only with process connection 10
46 CuZn (brass)
20 CrNi (stainless steel 1.4571)
