Technical data
Electrical data
Approvals/approval marks
Operating data
Switching element ETH-20 ETH-70 ETH-70/U
Microswitch with changeover
contact Microswitch with N/C contact and
restart lock Microswitch with N/C contact,
restart lock, and additional signal
contact
Maximum switching capacity AC 230 V +10 %, 10 (2) A, cos ϕ = 1 (0.6), DC 230 V +10 %, 0.25 A
With switching differential 2%
AC 230 V +10 %, 6 (1.2) A,
cos
ϕ = 1 (0.6),
- - - -
Microswitch, gold-plated, extra code /au
AC / DC 24 V, 0.1 A
Contact resistance 2.5 to 10 m
Ω
- -
Contact reliability To ensure a high switching reliability, we recommend a minimum load of:
With silver contacts:
AC / DC = 24 V, 100 mAt With gold-plated contacts (abbreviation "au":
AC / DC = 10 V, 5 mA
Type Switching
function DIN register no. Tests Important note !
ETH-20 STW (STB) STW (STB) 799S Pressure Equipment
Directive 97/23/EC
CE0036 The DIN registry no. will
become null and void if
thermowells are used that are
not specified in our data sheet
606710.
ETH-70 STB STB 800
Switching differential in %
from the control range / limit
value range Switching function With liquid-filled measuring system
Nominal value Possible actual value
STW (STB) 5 4 max. 6 Standard
9 8 max. 11 Upon request
2 1 max. 3 Extra cost
With liquid-filled measuring system
7 5 max. 12 Standard
9 8 max. 16 Upon request
2 1.5 max. 3 Extra cost
Switching point accuracy in
% of the limit value range
In the upper third of the scale +0/-5 %, at scale beginning +0/-10 %
Ambient temperature
influence referring to
the control range / limit value
range When the ambient temperature on the switching head deviates from the calibration
ambient temperature of +22 °C, a switching point offset occurs.
Higher ambient temperatures = lower switching point
Lower ambient temperature = higher switching point
Panel-mounted thermostats with scale limit value
< 200 °C ÷ 200 °C ≤ 350 °C > 350 °C ≤ 500 °C
Influence on the switching head
0.17%/K 0.13%/K 0.12%/K
Influence on the capillary per meter
0.054%/K 0.11%/K 0.03%/K
Allowable storage
temperature -50 to +50°C
Allowable ambient
temperature when in use:
Max. +80 °C
Rated position (NL) Any
