Technical data
Switching head
Process connection
Note:
Physical and toxic features of the expansion mediums that could emerge in the event of a measuring system break.
Chassis material Sheet steel, galvanized
Mounting 2 M3 screws, spacing 22 mm
Scale range 250 ° Մ
Electrical connection Screw connection up to 2.5 mm
2
conductor cross section
Limit value setting Prior to installation, the limit value can be set on the adjusting spindle with a screwdriver
Protection type EN 60 529-IP 00
Weight Approx. 0.2 kg
ETH series
with capillary Plain cylindrical probe "10" (standard)
Screw-in thermowell "20" (upon request)
Screw-in sleeve with screw-in spigot G 1/2 form A according to DIN 3852/2 and clamping piece with fixing
screw to lock the probe
Material Up to +150 °C CuZn (nickel-plated) as standard, over +150 °C CrNi
Insertion length Standard lengths: 100, 120, 150, 200, or 300 mm (different lengths upon request)
Immersion tube Ø D = 8 mm
For different process connections and thermowells refer to data sheet 606710
Control range with scale limit
value Hazardous
reactions
Fire and explosion hazard Hazardous to
water
Specifications about toxicology
Ignition
temperature
Explosion
limit
Irritant Dangerous to
health
Toxic
< +200 °C
No
+ 355 °C 0.6 - 8 V% Yes Yes
a
a There is currently no statement by the health authority concerning hazards to health in the event of short-term exposure and low concentration, e.g. measuring
system break.
No
≥
200°C ≤ +350 °C + 490 °C - - Yes Yes a
> 350 °C ≤ +500°C No No No No No
