Order details
Panel-mounted thermostat JUMO heatTHERM type 602030 and 602031
Minimum purchase order 500 pieces
Order code
( 1 )
Basic type
602030
Panel-mounted thermostat JUMO heatTHERM with single-pole snap-action switch (TR/TW)
602031
Panel-mounted thermostat JUMO heatTHERM with single-pole snap-action switch (STW/STB)
( 2 )
Basic type extensions
x
01
Temperature controller (TR)
With changeover contact
x
02
Temperature monitor (TW)
With changeover contact
x
20
Safety temperature monitor (STW)
Permanently set with change-
over contact
x
21
Safety temperature monitor (STW)
Adjustable with changeover
contact
x
80
Safety temperature limiter (STB)
Permanently set with changeover contact
and restart lock
x
81
Safety temperature limiter (STB)
Adjustable with changeover
contact and restart lock
( 3 )
Control range / limit value range °C
Max. allowable probe temperature °C
x
x
000
With permanently set switching point
x
026
0 to +120
145
x
028
0 to +200
230
x
041
+20 to +90
115
x
064
+50 to +300 (temperature probe made of CrNi)
345
x
043
+20 to +150 (only with extra code 749)
180
x
640
+50 to +300 (temperature probe made of CrNi,
only with extra code 749)
345
x
666
+95 to +120
145
x
671
+70 to +130
155
Further control ranges / limit value ranges up to 350 °C upon request (up to +500 °C without approval)
( 4 )
Limit value STW/STB permanently set °C
Max. allowable
probe tempera-
ture °C
Switching point tolerance
x
000
With adjustable limit value
x
095
+95
145
+0/-5 K
x
100
+100
145
+0/-5 K
x
110
+110
145
+0/-5 K
Further limit values up to 350 °C upon request (up to +500 °C without approval)
( 5 )
Switching differential %
x
00
No specifications for STB
x
25
2.5
x
x
70
7
( 6 )
Capillary length mm
x
x
2000
2,000
x
x
Special length upon request (maximum length 5,000 mm), specifications in plain text - 1,000 mm steps
( 7 )
Capillary material
x
x
40
Cu (copper) Ø 1.25 mm
