Data Sheet 70.9040
M. K. JUCHHEIM GmbH & Co • 36035 Fulda, Germany
Page 3/12
Features
Two single-phase units can be linked into an economy circuit in burst-firing operation
-
free-running economy circuit for resistive loads
-
master-slave economy circuit for resistive and transformer loads
Subsidiary controls
U
2
control as standard.
With extra code TR or TO: free choice between U
2
, P, I
2
control via internal switches.
Power level output
U
2
signal as standard.
With extra code TR or TO: free choice between U
2
, P, or I
2
signal via internal switches,
adjustable 0 — 5 V to 0 — 10V. I
max
≈
2 mA.
Electrical connection
Control wiring by screw terminals for conductor cross-sections 0.2 — 2.5mm
2
.
Load connections by cable lugs to DIN 46 212.
Protection
IP00 to EN 60 529, grounded heatsink
Permitted ambient temperature range
0 — 45°C
Permitted current reduced by 2% for each °C increase in ambient temperature;
the maximum permissible ambient temperature must not exceed 60°C.
Permitted storage temperature range
-10 to +70°C
Climatic conditions
rel. humidity 75% max. annual mean, no condensation
Cooling
by natural convection
Operating position
vertical
Operating conditions
The thyristor unit is designed as a built-in unit to:
VDE 0160 5.5.1.3 (5/88)
VDE 0106 Part 100 (3/83)
pollution degree 2 to VDE 0110 Part 1 4.2 (1/89)
overvoltage category U III to VDE 0160 5.7 (5/88)
Test voltage
to VDE 0160 Table 4 (5/88)
Creepage distance
control electronics to load circuit 10mm min.
control electronics to housing
10 mm min.
Unit can be connected to SELV circuits.
SELV = Separate Extra Low Voltage
Housing
TYA110/3,
25 (50)
110 x 195 x 152mm
TYA110/3,
75 (100)
125 x 195 x 170mm
TYA110/3, 150
(250)
150 x 220 x 280mm
Weight
TYA110/3,
25 (50)
2.8 kg
TYA110/3,
75 (100)
3.7 kg
TYA110/3, 150
8.6
kg
TYA110/3
250
9.0 kg
Standard accessories
1 mounting plate for wall-mounting
1 Operating Instructions B 70.9040
