Screen
Electrical data
Case and ambient conditions
Approval/approval marks
Type Touchscreen TFT color monitor
Size 21.3 cm (8.4”)
Resolution 640 × 480 pixels
Number of colors 256 colors
Frame rate > 150 Hz
Brightness setting Adjustable on the device
Screen saver (shutdown) Via waiting time or control signal
Voltage supply
Connection At the case bottom (removable terminal strip, 2-pin with Push-In technology)
Voltage DC 24 V +25/-20 % SELV
Residual ripple 5 %
Current consumption Max. 750 mA (at DC 19.2 V)
Power consumption Max. 15 W
Conductor cross section (voltage supply)
Wire or strand without ferrule Min. 0.5 mm 2 , max. 2.5 mm 2
Strand with ferrule Min. 0.5 mm 2 , max. 2.5 mm 2
2 x strand with twin ferrule with plastic collar Min. 0.5 mm 2 , max. 1.5 mm 2 (both strands with the same cross section)
Stripping length 10 mm
Electrical safety Acc. to DIN EN 61010-1
Overvoltage category III, pollution degree 2
Electromagnetic compatibility Acc. to DIN EN 61326-1
Interference emission Class A – only for industrial use –
Interference immunity Industrial requirements
Case type Metal case for mounting into a panel cut-out (indoor use); front with decor foil
Dimensions (W × H × D) 235 mm x 195 mm x 58 mm (without connection elements)
Weight (fully equipped) Approx. 1.8 kg
Protection type Front IP67, rear IP20, acc. to DIN EN 60529
Ambient temperature range -20 to +55 °C
Storage temperature range -30 to +70 °C
Resistance to climatic conditions Relative humidity ≤ 90 % annual average without condensation (climatic class 3K3
acc. to DIN EN 60721-3-3 with extended temperature and humidity range)
Site altitude Up to 2000 m above sea level
Mechanical ambient conditions a
a Test conditions are listed in the System Descripton B 705000.8.
Vibration test acc. to DIN EN 50178
Shock test acc. to DIN EN 60068-2-27
Drop test acc. to DIN EN 60068-2-32
Approval mark Testing agency Certificate/certification
number Inspection basis Valid for
c UL us Underwriters Laboratories E201387 UL 61010-1 (3. Ed.),
CAN/CSA-22.2
No. 61010-1 (3. Ed.) all types
