JULABO FP89-ME Ultra-Low Refrigerated Circulators - Manual (Page 25)

ME
25
Example: Adjustment/modification of the pre-setting of
"SETPOINT 3"
1. Press the key.
2. Select SETPOINT 3 by pressing the key.
Example: SETPNT 3 / 70.00 °C
3. Keep the key pressed until the integer digits flash .
(example: <70>)
4. Adjust value by pressing the key and the key to 85.00 °C
and confirm by pressing the key.
The decimal digits flash and can be adjusted if desired.
Confirm once more by pressing the key.
Example on the left: SETPNT 3 / 85.00.

If the active setpoint (SETPNT) is changed, the new value is
immediately used for the control of the working temperature.
The heater control indicator flashes.

If the other two setpoints (not activated for control) are changed the
MENU has to be left by pressing the key after the decimal
digits have been confirmed
Notice: Refer to SETPOINT MAX / MIN in chapter
9.8. MENU LIMITS
7.2. Direct setting of temperatures
The circulator uses the setpoint of SETPNT 1 or 2 or 3 for temperature
control
The indicated setpoint temperature can be changed directly any time.
Example: change 25.00 °C to 50.00 °C
1. By pressing the key the circulator switches to the active
SETPOINT< example on the left: >SETPNT / 1 25.00°C<.
The integer digits flash
(example: <25>).
2. By pressing the keys and the value is changed to
50.00 °C and
is confirmed by pressing the key.
The decimal digits flash and can be adjusted if desired.
Confirm once more by pressing the key.

The circulator uses the new working temperature value for temperature
control.

The temperatures can be set in start or stop mode.
