Page 8

Operator responsibility – Safety instructions
8
2.4. Technical
specifications
FC(W)600
FC(W)600S
Working temperature range
°C -20 ... 80 -10 ... 80
Cooling capacity
°C 20 5 -10
20 5 -10
(water-glycol)
kW 0.6 0.4 0.21
0.5 0.3 0.1
Refrigerant
R134a
Heater capacity
kW
1.2
Pump capacity:
Pressure max.
psi 7.25
17.4
Flow rate max.
Lpm 20 / 14
22 / 15
with tubing connections
mm dia 13,5/9,5
13,5/9,5
Pump connections
M16x1
M16x1
Noise level, 1 m distance
dBA 51
54
Filling volume
l
6 ... 8
Dimensions (WxLxH)
mm
350 x 540 x 490
Ambient temperature
°C
5 ... 40
Shipping weight
kg 48
52
Mains power connection
V/Hz
230/50 or 208 - 230 / 60
Total power consumption
W 2000
2300
FC(W)1200
FC(W)1200S
Working temperature range
°C -20 ... 80 -15 ... 80
Cooling capacity
°C 20 5 -10
20 5 -10
(water-glycol)
kW 1.3 0.75 0.37
1.2 0.65 0.26
Refrigerant
R134a
Heater capacity
kW
1.2
Pump capacity:
Pressure max.
bar 0.5
1.2
Flow rate max.
l/min 20 / 14
22 / 15
with tubing connections
mm
13,5/9,5
13,5/9,5
Pump connections
M16x1
M16x1
Noise level, 1 m distance
dBA 53
57
Filling volume
l
8 ... 11
Dimensions (WxLxH)
mm
460 x 610 x 490
Ambient temperature
°C
5 ... 40
Shipping weight
kg 60
66
Mains power connection
V/Hz
230/50 or 208 - 230 / 60
Total power consumption
W 2300
2800
All data have been determined at
mains voltage: 230 V / 50 Hz
ambient temperature: 20 °C
bath liquid: water-glycol
