Operating controls and functional elements
14
4. Operating controls and functional elements
1.
Mains power switch, illuminated
7.
Filling
funnel
8.
Drain
tubing
9.
Drain
tap
10.
Filling level indication
11.
Pump pressure gauge
10.
7.
11.
8.
9.
1.
2.
MULTI-Display temperature indication
(LED 1 + LED 2)
3. Indicator
lights
Alarm
Heating
Cooling
Temp.
Control
= Keypad control mode
= Remote control mode
