DAILY CLEANING
Lift handle. Remove brew chamber and cup.
Wipe down sprayhead with a soft cloth to
remove any residue. Once a month, or as
use necessitates, rotate sprayhead coun-
terclockwise and remove as illustrated.
Clean & lube guides as needed.
SPRAYHEAD REMOVAL
CHECK VALVE REMOVAL
Push the check valve up from underneath
the cup support.
Thoroughly wash sprayhead, cup and check valve (with
mild soap and water) and rinse with fresh water. Wipe
out the cap area above sprayhead and around O-rings.
Replace sprayhead by rotating clockwise, take care not
to over tighten or cross thread the sprayhead when
reinstalling.
Thoroughly flush the check valve while pushing the
center poppet open with a probe.
42822.1 110411
Clean & inspect parts daily.
Replace if loose, cracked or damaged.
STOP!
DO NOT LUBE
THIS O-RING
After cleaning, apply very light film of silicon
lube (included) to O-rings & check valve (1-4)
3.
1
2
4
