Intelix AVO-MIC-F User Manual
Avo cat, Series, Specifications

Specifications
Specifications subject to change without notice.
Maximum Distance*
2,500 feet
Output Impedance
600 ohms, balanced
Bandwidth
20 Hz to 20 kHz
Isolation
500 V
Nominal Output Level
0 dBu - (+16 dBu pk)
Common Mode Rejection
Greater than 50 dB
Power
24 VAC; system may be powered at either the send or receive end
Power Connector
DIN connector
Unshielded Twisted Pair
Maximum capacitance: 20 pf/foot
Cabling Specifications
Impedance: 100 ohms @ 1 MHz
(24 gauge or lower solid
Attenuation: 6.6 dB/1000 ft. @ 1 MHz
copper)
Cat 5, Cat 5e, Cat 6, Cat 7 compatible
Audio Connectors
One (1) 3-pin screw terminal to one (1) RJ45
Phantom Power
24V
System Gain
0 to 60 dB
RJ45 Pinout
Audio: 1 & 2, pair 2
Power: 4 & 5, pair 1
Temperature
Operating: 32 to 131 F (0 to 55 C)
Storage: -4 to 185 F (-20 to 85 C)
Humidity: up to 95%
Enclosure
Black plastic
Dimensions
Receive unit: 4.3” x 2.5” x 1.0”
Send unit: 4.3” x 2.5” x 1.0”
Shipping Weight
2.0 lbs (3.2 oz.)
Ordering Information
AVO-MIC-F: includes send balun, receive balun, and power supply
Warranty
2 years
* Distances and audio quality may be affected by cable grade, cable quality, source and
destination equipment, RF and electrical interference, and cable patches. Intelix
specifications are based on straight-through cabling with standard-grade Cat 5.
Contact Information
Intelix
2222 Pleasant View Road
Middleton, WI 53562
Toll-free: 866-4-MATMIX
Phone: 608-831-0880
Fax: 608-831-1833
www.intelix.com
[email protected]
Intelix AVO-MIC-F Microphone Balun Set
Installation Manual
Installation Manual
Installation Manual
Installation Manual
Installation Manual
The Intelix AVO-MIC-F microphone balun set transmits a preamplified microphone
signal and phantom power up to 2,500 feet over standard structured cabling, such as Cat
5. The AVO-MIC-F balun set includes a rack-mountable send balun, rack-mountable
receive balun, and a power supply; the set may powered on either the send or receive end.
The AVO-MIC-F balun set is ideal for corporate A/V, churches, schools, auditoriums, and
almost any other situation involving microphone level audio signal distribution.
The Intelix
AvoCat Series of baluns is the ideal solution for sending audio and video over
structured cabling. When signal quality matters, choose Intelix.
To install an AVO-MIC-F balun, perform the following steps:
1. Identify the pin configuration of the baluns. Two (2) twisted pairs are required:
one for audio and one for power (if powering either balun remotely). The pin
configuration follows the EIA/TIA 568A/B standard. Please ensure that wiring is
straight-through.
2. Connect the AVO-MIC-F send balun to the audio output of the audio source using
an audio cable.
3. Connect the AVO-MIC-F receive balun to the audio input of the audio destination
using an audio cable.
4. Complete the connection between the two baluns using standard twisted pair
cable, such as Cat 5. Verify the Cat 5 is terminated with RJ45 connectors on both
ends which conform to the EIA/TIA 568A or 568A crimp standards. Ensure that
there are no split pairs or taps.
5. Connect the included power supply to either the send or the receive balun.
6. Power-on the audio equipment.
7. On the receive balun, EQ the balun pair by selecting the overal distance of the
system. Set the EQ switch to either less than or equal to 1,500 feet or greater than
1,500 feet.
8. On the send balun, select whether phantom power is engaged or not. Then
adjust the overall system gain between 0 and 60 dB.
Installation
Caution: Do not attempt to open the balun housing. There are no user-serviceable parts
inside the AVO-MIC-F. Opening the unit will void your warranty.
Caution: Do not mount the balun over equipment ventilation openings. Covering the
openings may cause the equipment to overheat.
AvoCat
Series
Caution: Do not connect the AVO-MIC-F to a telecommunication outlet wired
to unrelated equipment. Making such a connection may damage the
equipment and/or balun. Please ensure all wiring is “straight-through.”
AVO-MIC-F
