Instructions
1. Verify all components included with the extender set are present before
installation.
2. If the extenders are going to be permanently mounted to a surface, attach
the included mounting brackets with the supplied screws.
3. Turn off power and disconnect the audio/video equipment by following the
manufacturer’s instructions.
4. Connect Category 6 or greater twisted pair cable with RJ45 connectors
between the transmitter (DL-HD70-TX) and the receiver (DL-HD70-RX). TIA/
EIA-568B straight-through wiring connections must be used with all HDBaseT
extenders.
5. Connect an HDMI cable and any desired control accessories between the
display and the receiver (DIGI-HD70-RX).
6. Connect an HDMI cable and any desired control accessories between the
source and the transmitter (DIGI-HD70-TX).
7. Connect the included power supply to the transmitter or receiver and lock
the power supply to the power connector by twisting the locking collar counter
clockwise.
8. Power on attached audio/video devices.
Passing IR Signals:
The DL-HD70 is capable of passing IR signals between 33 and 55 KHz. To
prevent damage to any of the electronics, the extenders should be powered
off while inserting or removing any IR components. Inserting an IR transmitter
into the IR IN port may damage the IR circuit for that extender.
IR OUT: The IR transmitter (IR emitter) must be plugged into the IR OUT port.
IR IN: The IR receiver (IR eye) must be plugged into the IR IN port.
Important notice:
• Do not attempt to disassemble or alter the extender housing. There are
no user-serviceable parts inside the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic
discharge (ESD), all source and destination equipment must be powered off
during installation.
• Do not connect the extender to a telecommunication outlet wired
to unrelated equipment. Doing so may damage the unit or any connected
equipment. Ensure all connected twisted pair cabling is straight-through
(point-to-point).
• Allow proper ventilation to reduce the risk of thermal failure.
