Technical Specifications
Video Amplifier Bandwidth
1.65 Gbps
Supported Video Resolutions
480i, 480p, 576i, 576p, 720p, 1080i
Max Recommended Distance
150 feet
Input Video Signal
1.2 volts p-p
Input DDC Signal
5.0 volts p-p (TTL)
Input Unit Connectors
(1) Type A HDMI connector to (2) RJ45s
Output Unit Connectors
(2) RJ45s to (1) Type A HDMI connector
Cabling
Two individual runs of Cat 5e or Cat 6
Power
External 5 VDC
Power Connector
Powered on either send or receive end; side mounted
connector
Dimensions
3.25” x 1.75” x 0.88”
Temperature
Operating: 0° to 55°C
Storage: -20° to 85°C
Humidity: up to 95%
Shipping Weight
1 lb.
Warranty
2 years
Regulatory
CE, RoHS
Intelix Part Number
DIGI-HDMI-HR
Ordering Information
DIGI-HDMI-HR package includes one send unit, one
receive unit, two mounting brackets and one power
supply
The Intelix DIGI-HDMI-HR conforms
to HDMI and HDCP specifications.
Intelix does not guarantee operation
with devices that do not conform to
these specifications. The Intelix DIGI-
HDMI-HR passes HDCP signals and
does not manipulate them in any way.
Distances and picture quality may be
affected by cable grade, cable quality,
source and destination equipment, RF and
electrical interference, and cable patches.
Intelix specifications are based on
straight-through cabling with standard-
grade Cat 5e.
