10 tina52e1-d (2014-02)
2 Technical Data
For further technical data for gauges with DeviceNet,
Profibus or EtherCAT interface →  [5], [6], [7].
Measurement range → "Validity"
Accuracy 1)
≤0.5 Torr/mbar F.S.
≥1 Torr/mbar F.S.
0.4% of reading
0.2% of reading
Temperature effect on zero
≤0.5 Torr/mbar F.S.
≥1 Torr/mbar F.S.
0.0050% F.S./ °C
0.0025% F.S./ °C
Temperature effect on span 0.02% of reading / °C
Resolution 0.003% F.S.
Gas type dependence none
Output signal analog
(measurement signal)
Measurement range 0 … +10 V
Voltage range –5 … +10.24 V
(limited to +10.24 V)
Relationship voltage-pressure linear
Output impedance 0 Ω (short-circuit proof)
Loaded impedance >10 k Ω
Response time 2)
≥0.25 Torr/mbar (F.S.)
0.1 Torr/mbar (F.S.)
30 ms
130 ms
Identification
Resistance R
Ident
Voltage
13.2 k
Ω referenced to
supply common
≤5 V
1)
Non-linearity, hysteresis, repeatability in the calibrated range at 25 °C
ambient operating temperature without temperature effects after
operation of 2 h.
2)
Increase 10 … 90 % F.S.R.
