Cool Drawer Single and Dual Sensors Operating Manual
1.4 Unpacking and Inspection
1
If the Cool Drawer sensor has not been removed from its packaging, do so now.
The sensor and accessories are packaged in a single cardboard carton with a
rigid foam insert. Carefully remove the packaged accessories before removing
the sensor.
2
Carefully examine the sensor for damage that may have occurred during
shipping. This is especially important if obvious rough handling is noticed on the
outside of the container. Immediately report any damage to the carrier and to
INFICON.
NOTE: Do not discard the packing materials until inventory has been taken
and the sensor has been successfully installed.
3
Take an inventory of the order by referring to the order invoice and the
information contained in
4
Install the sensor by following the installation instructions found in
.
For additional information or technical assistance, contact INFICON (refer to
).
1.5 Cool Drawer Single Sensor (PN CDS-XXXXX)
Figure 1-2 Standard sensor
Figure 1-3 Right Angle sensor
