7
SuperLogic 2500 Manual
Pre-InstallaƟ on Procedures
PLEASE READ CAREFULLY. FAILURE TO FOLLOW THESE PROCEDURES CAN RESULT IN DAMAGE TO YOUR SYSTEM AND VOID YOUR
WARRANTY.
Packaging
Upon delivery, inspect packaging and report any damage to your carrier immediately. A er unpacking the system,
inspect it carefully for signs of damage. All damage claims should be made to the delivery carrier.
OperaƟ ng Parameters
The SuperLogic 1500 system may only be used on potable water. The user must be sure that water to be treated is both microbio-
logically safe and non-toxic. Ensure that the opera ng parameters outlined on page 3 are met at the installa on site. Items of most
importance are TDS, feed water pressure, fl ow rate, chlorine level and temperature range. A water analysis is helpful in determining
if any pre-treatment is needed. If your water analysis shows levels of substances in excess of the maximums, contact HydroLogic for
pre-treatment recommenda ons. Contact HydroLogic to inquire about a detailed water analysis.
InstallaƟ on/Start up Procedure
PLEASE READ CAREFULLY. FAILURE TO FOLLOW THESE PROCEDURES CAN RESULT IN DAMAGE TO YOUR SYSTEM AND VOID YOUR
WARRANTY.
LocaƟ on
Locate the system where it will be protected from harsh condi ons such as rain, snow, direct sunlight and extreme temperatures
(both hot and cold). The SuperLogic 1500 system can be located just about anywhere there is a water supply and electrical outlet.
This system is equipped with casters and may be rolled to diff erent loca ons for opera on. Keep in mind, however, that the system
should be out of normal traffi
c pa erns yet accessible for daily monitoring and service.
Plumbing
(Figure 1 - Flow Diagram)
Always abide by local plumbing codes when installing the system.
Water Supply ConnecƟ on
Connect feed water supply line to the female garden hose connector. Many other inlet fi ng op ons are available through Hydro-
Logic. If the supply water is being drawn from a non-pressurized source (gravity feed), contact Hydrologic for addi onal informa on.
Minimum inlet pressure is 40 psi. If your inlet psi is below 40 contact HydroLogic for further informa on.
Drain ConnecƟ on
Connect a 3/8” line from the quick connect elbow marked DRAIN to an appropriate drain point. A quick connect drain saddle is avail-
able as an op on from HydroLogic and can be plumbed directly into the main train of a sink. Be sure to check your local plumbing
codes to see if an air gap between the system and the drain is required.
Product ConnecƟ on
The product water connec on to the storage tank should not be made un l the system is fl ushed and tested as outlined below.
Tank ConnecƟ on (For Non-Pressurized Tanks Only)
When using a non-pressurized storage tank, connect the 3/8” tubing marked PRODUCT to the tank. Use an op onal electronic fl oat
switch to shut down the system when the tank is full and start the system when water level is low. Quick connect bulk head fi ngs
are available to connect the product line to your tank. Contact HydroLogic for this and other op ons available.
