1

83 Water Street • New Haven, CT 06511 • Phone (203) 776-0473 • FAX (203) 773-1019 •

www.hydrolevel.com

MODEL 3150

Combination Low Water

Cut-Off & Universal

Temperature Limit Control

for Oil-Fired Boilers

PATENT NO. 7,891,572

INSTALLATION INSTRUCTIONS
and OPERATING MANUAL

• Replaces Common Aquastat

*

Models – Can be installed on existing immersion

wells to replace both cold-start and triple-action Aquastats

®

. Industry standard wiring

designations make change-outs quick and easy.

• Digital Display – Easy to read LED continually displays boiler temperature. Also displays

temperature limit and differential settings during adjustment.

• Easy to Set – Dials for setting temperature limits and differentials eliminate complicated

programming.

• Thermal Pre-Purge Feature – Conserves fuel and meets 2012 DOE regulations by

circulating latent heat in the boiler to the heating zone before firing the burner.

*Aquastat is a registered trademark of Honeywell International, Inc.

WARNING

Electrical shock hazard. To prevent electrical shock, death or
equipment damage, disconnect power supply before

installing or servicing control. Only qualified personnel may install or service this control in
accordance with local codes and ordinances. Read instructions completely before proceeding.

CAUTION

To prevent serious

burns, boiler

should be thoroughly cooled before installing or
servicing control.

WARNING

Frozen pipes/water damage. Central heating systems are prone to shut down as a result of power or fuel outages,
safety related fault conditions or equipment failure. Installation of freeze protection monitoring or other precautions

is recommended for unattended dwellings in climates subject to sustain below-freezing temperatures.

Dual Function
Design

Temperature Limit Control

Designed for cold start and tankless

coil boilers.

Low Water Cut-Off

Provides protection against potentially

dangerous low water conditions

when installed with the Hydrolevel

Electro-Well™ (see page 2 for details).

HydroStat 3150 Instructions Page 1
