HMG 3010 Page 79
Edition 11/2011 - V04 R01 Part No.: 669855
Battery life (from fully charged)
• HMG 3010 without sensors approx. 11 hours
• HMG 3010 with 2 sensors approx. 9 hours
• HMG 3010 with 4 sensors approx. 7 hours
• HMG 3010 with 8 sensors approx. 4 hours
Sampling rates
• Sampling rate: 0.1 ms .. 1 min
• Sampling rate: 0.1 ms for a maximum of two sensors (other sensor
inputs inactive); e.g. for pressure peak measurements
The sampling rate which can be set is dependent on the active measurement channels. The
following applies:
• 0.1 ms max. 2 analogue input channels
• 0.2 ms max. 4 analogue input channels
• 0.5 ms all 10 input channels
• 1.0 ms for SMART sensors
Measured value memory
• Single recording: up to 500,000 measured values
• Archive memory: 128 MB
(for min. 100 individual recordings)
PC link interfaces
• USB port
• Serial interface (RS 232)
For communication and evaluation using the HYDAC HMGWIN 3000 or CMWIN
software and using HSP log
Dimensions and weight
• Dimensions: 246 x 174 x 58 mm
• Weight: 1100 g
Operating and ambient conditions
• Operating temperature: 0 ... 50 °C
• Storage temperature: -20 ... 60 °C
• Relative humidity:
0 ... 70%
Technical standards
• EMC: EN 61000-6-1/2/3/4
• Safety: EN 61010
• Protection class: IP 40
Supply voltage
• 12 … 30V DC
