Separate
sensor
- 30 .. 150 °C
(-22 .. 302 °F)
-27 .. 150 °C
(-16 .. 302 °F)
1 .. 178 °C
(2 .. 320 °F)
1 °C
(2 °F)
* All ranges given in the table are adjustable by the increments shown.
6. Basic settings
In order to adapt the unit to a particular application, the function of the ETS 300 can be
altered via several basic settings. These are combined in one menu.
6.1 Altering the basic settings
Important note: when the menu is activated no switching operations are carried out.
Switch off supply voltage or disconnect the unit from the supply voltage.
3 s
display
(release
“mode” key)
mode
H
press “mode” key and
hold down. Switch
on supply voltage
(hold key down for 3s)
mode
H
mode
G
2 s
Use or to alter
setting, then select next
menu point .
press “mode” key until the
required menu point appears
in the display .
(for summary, see 6.2)
To close the basic setting menu:
Call up the menu point "END", set to "YES", the ETS 300 returns to the normal display
mode after 2 seconds.
Note:
· If after about 50 seconds no keys have been pressed, the menu automatically closes
down. Any changes which may have been made will not be saved.
