11. Model code

Series no.

(determined by manufacturer)

Type of connection, mechanical

2 = G1/2" A male thread
8 = electrical connection for separate sensor (TFP 100)

Type of connection, electrical

ETS 3 X X

- X - X

X X - 00

4 = 4-pole Binder plug, series 714 M18

5 = plug to DIN 43650, 3 pole + earth

(ZBE 01 connector included)

Output
1 = 1 switching output

2 = 2 switching outputs

3 = 1 switching output and 1 analogue output

Measurement ranges

100 = - 25 .. 100 °C (- 13 .. 212 °F) only for version with built-in sensor
150 = - 30 .. 150 °C (- 22 .. 302 °F) only for version with separate sensor

Modification number

000 = display in °C (determined by manufacturer)
400 = display in °F (determined by manufacturer)

(connector not included)

only available for output models “2” and “3”

only available for output model “1”

(only in conjunction with electrical connection type “5” or “6”)

(only in conjunction with electrical connection type “4” or “6“)

6 = 4 pole plug, M12x1

only available for output models “1”, “2” and “3”

(connector not included)

8 = 5 pole plug, M12x1

only available for output model “5”

(connector not included)

5 = 2 switching outputs and 1 analogue output

(only in conjunction with electrical connection type “8”)
