E

Installation

Installed as pressure gauge

The EDS 601 can be installed directly into the hydraulic system via the G ¼“

threaded connection or an adapter. Depending on the type of connection, the

sealing should be to DIN 3852 or DIN 16288. The torque should be within the

range 20..30 Nm. (Where adapted for G½“: 45..50 Nm).

Installed as front panel measuring unit

The unit is installed in a front panel cut-out of 68.5 x 68.5 mm. The unit is

secured with clamps from the mounting set, which can be ordered separately.

For mechanical de-coupling the hydraulic connection must be via a standard

small bore instrument hose. The sealing can be by means of an O-ring or a

metallic soft seal to DIN 3852. The torque should be within the range 20..30 Nm.
Note:

When installed as a front panel unit a rigid hydraulic connection

must not be used.

Making the electrical connection

The electrical connection should be carried out by a qualified electrician

according to the relevant regulations of the country concerned (VDE 0100 in

Germany).

The electronic pressure switches EDS 601 carry the mark. A declaration of

conformity is available on request.

The EMC-standards EN 50081-1, EN 50081-2, EN 50082-1 and EN 50082-2

apply.

The requirements of the standards are fulfilled only if the pressure switch

housing is earthed correctly by qualified personnel. If the pressure switch is

mounted inline, it is sufficient if the pipe is earthed via the hydraulic system. In

the case of hose-mounting, the housing must be earthed separately via the PE

connection of the 4-pole plug.

Additional assembly notes which, from experience, reduce the effect of

electromagnetic interference:

l Make line connections as short as possible.

l Use screened lines (e.g. LIYCY 4 x 0.5 mm

2

).

l The cable screening must be fitted by qualified personnel subject to the

ambient conditions and with the aim of suppressing interference.

l Direct proximity to connecting lines of user units or electrical or electronic

units causing interference must be avoided as far as possible.

2.

2.1.

2.2.

G

2.3.
