General data
Dimensions approx. 72 x 72 x 110 mm (W x H x D)
Housing material aluminium, anodised
Pressure ranges 16; 40; 100; 250; 400; 600 bar
Overload pressures 24; 60; 150; 375; 600; 900 bar
Burst pressure 300 % FS
Accuracy 1 % FS
Repeatability switching point 0.25 % FS typ.
Temperature range - 25...+ 70° C (-25...+ 85° C media temperature)
Temperature drift 0.5 %/10 K; typ 0.25 %/10 K FS
Safety type IP 65
Vibration resistance 25 g/0...500 Hz
Shock absorbency 50 g/ 1 ms
mark
EN 50081-1, EN 50081-2,
EN 50082-1, EN 50082-2
Connection supply voltage plug to DIN 43650/ISO 4400 (3 pol. + earth)
Connection relays plug to DIN 43651 (6 pol. + PE)
Pressure connection G¼" female thread, sealing to DIN 3852
Supply voltage DC 20...32 V
Current consumption approx. 120 mA
Starting current approx. 1.5 A (0.1 s)
Display 7-segment LED display, 4 digits, 13 mm high
Signal output 0...10 V ohmic resistance: min. 2
4...20 mA ohmic resistance max. 400
Limit frequency signal output 20 Hz
Relay outputs
Number/function 2 relays with change-over contacts
Switching voltage 0.1...250 V
Switching current 0.025...2 A
Switching capacity 50 W/ 400 VA
Reaction time approx. 10 ms (sensor + electronics + relays)
Life expectancy of contacts 10 mill. without load
1 mill. at nominal load
Technical data 5.
Note: FS (Full Scale) = relative to the full measuring range
