Heidolph SilentCrusher M - Manual (Page 52)

- 52 -
E
E
Peripheral Speed [m/sec] 12.2
Initial Particle Size [mm] < 2.0
Material PTFE / 1.4435
Sterilization Up to 130°C with wet chemicals; up to
180°C dry
Dispersion Tool 12 G
Characteristics
Values
Part Number 596-12020-00
Stator Diameter [mm] 12.0
Rotor Diameter [mm] 9.0
Gap Width Generator/Rotor [mm] 0.3
Width of Slot [mm] 2.0
Total Shaft Length [mm] 120
Maximum Immersion Depth [mm] 80
Minimum Immersion Depth [mm] 25
Volume [ml] 3 - 50
Peripheral Speed [m/sec] 8
Initial Particle Size [mm] < 0.4
Material PTFE / 1.4435
Sterilization Up to 130°C with wet chemicals; up to
180°C dry
Dispersion Tool 12 DF
Characteristics
Values
Part Number 596-12110-00
Stator Diameter [mm] 12.0
Rotor Diameter [mm] 9.0
Gap Width Generator/Rotor [mm] 0.3
Width of Slot [mm] 0.6
Total Shaft Length [mm] 115
Maximum Immersion Depth [mm] 75
Minimum Immersion Depth [mm] 25
Minimum Immersion Depth [mm]
under vacuum 35
Volume [ml] 25 - 250
Peripheral Speed [m/sec] 12.2
Initial Particle Size [mm] < 2.0
Material PTFE / 1.4435
Maximum Permissible Pressure 6 bar
Permissible Vacuum 20 mbar
Sterilization Up to 130°C with wet chemicals; up to
180°C dry
