Grayhill Multi-Deck Rotary Switches 71 Series - Manual (Page 2)

Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
Rotary Switches
Multi-Deck Rotary Switches
DIMENSIONS: Metric All dimensions are in millimeters
36° Angle of throw
terminal Detail
Rear Views 4mm Diameter Shaft–Style E and ES
Approx.
No. of Dim. Dim. Weight
Decks A B Grams
1 19,33 0,79 12
2 24,87 0,79 14
3 30,40 0,79 16
4 35,94 0,79 18
5 41,48 0,79 20
6 54,13 7,92 22
7 59,66 7,92 24
8 65,20 7,92 26
9 70,74 7,92 28
10 76,28 7,92 30
11 81,81 7,92 32
12 87,35 7,92 34
Angle C is 15° in 12 position switches and
36° in 10 position switches.
Ø 17,45
± 0,4
OF POSITION NO. 1
OF BUSHING FLATS
C
SEE
CHART
6,00 + 0,00
–0,08
C
L
C
L
M7,0 X 0,75 THREAD
14,27
± 0,4
DIM. A ± 1,2
DIM. B REF.
STUD PROJECTION
(SEE CHARACTER-
ISTICS)
Ø 4,00 ± 0,03
25,00 ± 0,5
8,00
± 0,3
GRAyHILL
12
1
3 4
6
7
8
9 10
11
Ø 12,70
± 0,4
19,05 ± 0,5
OVER TERMINALS
SEE DETAIL
SEE NOTE
2 5
30° Angle of throw
GRAyHILL
10
1
2 3
4
5
6
7 8
9
Ø 12,70
± 0,4
19,05 ± 0,5
OVER TERMINALS
SEE DETAIL
SEE NOTE
Note: Common location for a single pole per
deck switch. For common location on
multipole switches see circuit diagrams.
Grayhill part number and date code marked on detent cover label. Customer part number marked on request.
30° Angle
of throw
36° Angle
of throw
Switch is Viewed From Shaft End and Shown in Position No. 1.
Note: All common terminals are located above base terminals as shown.
CIRCuIt DIAGRAMS: Standard, Military and Metric
ONE POLE TWO POLE THREE POLE FOUR POLE FIVE OR SIX POLE
ONE POLE TWO POLE
C1
C2
C3
10
11
12
1
2
3 4
5
6
7
8
9
C
L
C4
C1
C2
C3
10 11
12
1
2
3
4
5
6
7
8
9
C
L
C1
C2
C3
C4
C5
C6 10
11
12
1
2
3 4
5
6
7
8
9
C
L
C
L
C1
C2
10
11
12
1
2
3 4
5
6
7
8
9
4
3 2
1
10
9
8
5
6
7
C1
C
L OF
BUSHING
KEyWAy
4
3 2
1
10
9
8
5
6
7
C1
C2
C
L
C1
10
11
12
1
2
3 4
5
6
7
8
9
C
L OF
BUSHING
KEyWAy
.034 ± .003
(0,86 ± 0,08)
.068 ± .005
(1,73 ± 0,13)
