Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com

Rotary Switches

Multi-Deck Rotary Switches

SERIES 54

1" Diameter, 1 Amp, Add-A-Pot

FEAtuRES
• Military Qualified MIL-3786/04
• Central Shaft Designed to Operate

MIL Potentiometer

• Mounting Plate Options Provide

Choice of Potentiometer

• Fixed Distance from Switch to

Mounting Plate

Military Qualified Style

Note: Common locations for a single pole per

deck switch. For common location on

multiple switches, see circuit diagram.

Number

Approximate

of

Dimension

Weight

Decks

A

Grams

1

1.024 (26,01)

60

2

1.370 (34,80)

67

3

1.716 (43,59)

74

DIMENSIONS

In inches (and millimeters)

Potentiometer Mounting

The two mounting plates shown below are supplied with

each switch.

Mounting Plate A

Mounting Plate B

Series 54M Add-A-Pot Switch is a concentric
shaft unit with provision for potentiometer
mounting. Outer shaft operates switch decks.
Inner shaft terminates in tapered tongue,
which allows any desired potentiometer to be
mounted. The Series 54M Add-A-Pot is qualified
to MIL-DTL-3786/4-3. Patent No. 3,297,830.

Grayhill part number and date code marked on detent
cover label. Customer part number marked on request.
Military part number marked when required.

DIM. A + .046 –.020

(+ 0,05 –0,51)

.642

± .015
(16,31
± 0,38)

NON-TURN TAB
.125 ± .003 (3,18 ± 0,08) WIDE By
.031 ± .003 (0,79 ± 0,08) THICK

.219 ± .005

(5,56 ± 0,13)

C

L OF NON-TURN

TAB

.375

± .015

(9,53

± 0,38)

1.162 ± .010

(29,51 ± 0,25)

DIA.

.125 + .001 –.002
(3,18 + 0,03 –0,05) DIA.

.250 + .001 –.002
(6,35 + 0,03 –0,05) DIA.

.250 ± .020
(6,35 ± 0,51)

.121 ± .015

(3,07 ± 0,38)

.375

± .020

(9,53

± 0,51)

.375

± .020

(9,53

± 0,51)

.250 ± .020
(6,35 ± 0,51)

.140 ± .062

(3,56 ± 1,57)

1.000

± .010

(25,4

± 0,25)

3/8-32 NEF-2A THREAD

INTEGRAL ASSEMBLy NUT,
DO NOT REMOVE

BUSHING KEyWAy .066 ± .002 (1,68 ± 0,05)
WIDE By .036 ± .003 (0,91 ± 0,08) DEEP FROM
A .375 (9,53) DIA.

GRAyHILL OR CUSTOMER PART NUMBER
MARKED ON SWITCH COVER UPON REQUEST.
MILITARy NUMBER MARKED ON ALL
QUALIFIED SWITCHES

.575

(14,61)

REF.

#1
THREAD

SEE
POTENTIOMETER
MOUNTING

1.170 ± .015

(29,72 ± 0,38)

OVER TERMINALS

12

9

8

7
6

4

3

2

1

5

11

10

30°

15°

.018 ± .005 (0,46 ± 0,13)

.052 ± .005 (1,32 ± 0,13)

1.265

(32,13)

DIA.

27.5

± 2

.098 ± .003
(2,49 ± 0,08) DIA. (3)

THROUGH BOLT

HOLE (2 EA.)

15
± 2

.245 ± .003
(6,22 ± 0,08) R.

.375 ± .003
(9,53 ± 0,08) R.

.261 ± .003
(6,63 ± 0,08) DIA. (1)

1.265

(32,13)

DIA.

15 ± 2

9

± 2

.437 ± .003
(11,10 ± 0,08) R.

.531 ± .003
(13,49 ± 0,08) R.

.380 ± .003
(9,65 ± 0,08)
DIA. (1)

.130 ± .003
(3,30 ± 0,08)
DIA. (2)
