EUCHNER Identsystem CIS3
071652-01-8/99 Subject to technical modifications page 22 / 23
11. Technical data
CIT3PL1N30-5000
Operating voltage:
15 - 28 V
Current consumption: 100 mA (max.)
Load current per output: 30 mA (max.)
Storage temperature 0 - 80°C
Ambient temperature 0 - 50°C
Read distance: 0 - 12 mm (see also page 18)
Centre offset: nominal ±10 mm (see also page 18)
Response time
(for 4 decimal digits):
40 msec. (max.)
Relative speed: max. 30m/min. (see also page 19)
CIT3SX1R1G05KS:
Operating voltage:
15 - 25 V
Current consumption: 140 mA (max.)
Storage temperature 0 - 80°C
Ambient temperature 0 - 50°C
Type of connection: Screw terminals
Line length (RS232): 5 m (max.)
Read distance: 0 - 12 mm
Write distance
(Static writing):
0 - 6 mm
Write time
4 decimal digits:
230 ms (max.)
32 decimal digits: 420 ms (max.)
The following values are set for the serial interface (V24, RS 232):
1 Start Bit
8 Data Bits
1 Parity Bit (even parity)
1 Stop Bit
Baud rate: 9600 baud
