EUCHNER Identsystem CIS3
071652-01-8/99 Subject to technical modifications page 21 / 23
10. Installation instructions for CIS3 data carriers
Please comply with the following points when installing the data carrier in order to comply
with the technical specifications contained in the data sheets for the CIS3 ident system even
in the case of flush installation in metal:
• On data carrier, Type CIS3P35X16SH01KH (Order No. 040045 or 071745), there must
be a minimum clearance of 5 mm per side with respect to the surrounding metal on the
long side (35 mm side). The short side (16 mm side) may directly adjoin the surrounding
metal.
• Data carrier, Type CIS3P35X16SH01KV (Order No. 040046 or 071746) can be installed
flush in metal with no problems.
No minimum clearance with respect to the surrounding metal needs to be complied with
on any side.
