EUCHNER Identsystem CIS3
071652-01-8/99 Subject to technical modifications page 12 / 23
Byte
No. Description
ASCII
C O N T E N T S
HEX
Decimal
0 Number of telegram Bytes 8 ... 23
1
2 Command
identification R
L 52
4C 82
76
3 Read/write head address *) 01 01
4
5 Start address of
user data 00
0 ... Fh 00
0 ... 15
6
Number of Bytes of
user data
1 ... 10h 1 ... 16
7 ... 22 User data ASCII or HEX resp. BCD (code-transparent)
Figure 8: Response telegram "Read data carrier" (telegram core)
Byte
No. Description
ASCII
C O N T E N T S
HEX
Decimal
0 Number of telegram Bytes 7
1
2 Command
identification R
F 52
46 82
70
3 Read/write head address *) 01 01
4
5 Padding data 00
00 00
00
6 Error number Error No.
Error number f = 02: Data carrier not in active area
Figure 9: Response telegram "Read data carrier" (telegram core)
*) For downward compatibility with the CIS2 identification system.
The content of the header address must always by 1 in the case of CIS3.
