E T C S o u r c e F o u r L E D Q u i c k G u i d e
Features
Source Four LED Profile Page 6 of 8 Electronic Theatre Controls, Inc.
Tungsten and Daylight
Quick Setup Features Recommended For:
Studio
Linear dimming, simple standalone operation
via the UI. Video or film lighting, installations without
DMX control.
Stage
Tungsten-like dimming, stage-friendly
settings, DMX fan control. Theatrical lighting, installations mixed with
tungsten.
Single
Channel
Standard dimming, automatic fan, only 1
DMX channel. Architectural applications with streamlined
control.
Parameter Studio Stage Single Channel
DMX Settings
Profile Intensity Intensity Intensity
Strobe Enabled Enabled Disabled
Data Loss Setting N/A Instant Instant
Fan Control DMX DMX Automatic
LED Settings
Output Setting Regulated Regulated Regulated
Dimming Curve Linear Incandescent Standard
Local Settings
Status Indicators On On On
Overtemp Visible Dark Dark
