ETC Source Four LED v1.6.0 Quick Guide - Manual

E T C Q u i c k G u i d e
Source Four LED
™
Profile
Source Four LED Profile Page 1 of 8 Electronic Theatre Controls, Inc.
Corporate Headquarters  3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA  Tel +608 831 4116  Fax +608 836 1736
London, UK  Unit 26-28, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK  Tel +44 (0)20 8896 1000  Fax +44 (0)20 8896 2000
Rome, IT  Via Pieve Torina, 48, 00156 Rome, Italy  Tel +39 (06) 32 111 683  Fax +44 (0) 20 8752 8486
Holzkirchen, DE  Ohmstrasse 3, 83607 Holzkirchen, Germany  Tel +49 (80 24) 47 00-0  Fax +49 (80 24) 47 00-3 00
Hong Kong  Rm 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong  Tel +852 2799 1220  Fax +852 2799 9325
Service: (Americas)
[email protected]  (UK) [email protected]  (DE) [email protected]  (Asia) [email protected]
Web: www.etcconnect.com  Copyright © 2014 ETC. All Rights Reserved.  Product information and specifications subject to change.
7460M1300-1.6.0  Rev A  Released 2014-02  ETC intends this document to be provided in its entirety.
Overview
For complete information and step-by-step instructions, see the Source Four LED Profile User Manual.
ETC documentation can be downloaded at
www.etcconnect.com .
Accessory
holder
Yoke
Accessory
retainer
Yoke
locking knob
Safety cable
loop
LCD
DMX Thru
DMX In
Keypad
Power In
Power Thru
Status
indicators
Light Bulb
Home
Back
Up
Enter
Down
Power – Indicates AC power is On.
DMX – Indicates control signal is Active.
Error – Indicates data error, high temperature, or other unusual status.
