E T C D e s i r e Q u i c k G u i d e
Desire D22, D40, D40XT, D60 v1.6.0
D22, D40, D40XT, D60 v1.6.0 Quick Guide
Page 4 of 8
Electronic Theatre Controls, Inc.
To select a Quick Color:
Step 1:
Press the [
] to access the Presets and Sequences screen.
Step 2:
Within the Presets and Sequences screen, scroll to Quick Color and press [
].
Step 3:
Scroll to Color and press [
].
Step 4:
Scroll to the desired color and press [
].
Step 5:
Scroll to adjust the fixture’s intensity and press [
] to commit the selection.
Step 6:
To exit the Quick Color menu, press [
].
Quick Setups
D40, D40XT and D60 – Vivid, Lustr+, Fire, Ice, Studio HD
D22 – Lustr+, Studio HD
Quick Setup
Features
Recommended For:
General
Smooth dimming, good consistency, direct
color control.
General lighting, rentals, indoor applications.
Stage
Tungsten-like dimming, HSI color control with
Plus-7 fine tuning.
Theatrical lighting, installations mixed with
tungsten.
XT Arch
Maximum consistency in extreme
applications, reduced brightness.
High-temperature environments, installations
with limited access.
High Impact
Maximum brightness, quick response, RGB
color control, reduced consistency.
Video-based control, effects lighting, concerts.
Studio
Three-point control—White Point (CCT),
Intensity and Tint; standalone operation.
Video and film lighting, white light-only
applications.
Parameter
General
Stage
XT Arch
High Impact
Studio
DMX Settings
Profile
Direct
HSI
HSI
RGB
Studio
Strobe
Enabled
Enabled
Enabled
Enabled
Enabled
Data Loss
Setting
Instant
Instant
HLL-4ever
Instant
N/A
Plus Seven
N/A
Enabled
Disabled
Disabled
Disabled
Fan Control
(D60 only)
DMX
DMX
DMX
DMX
DMX
LED Settings
Output Setting
Regulated
Regulated
Protected
Boost
Regulated
Dimming
Curve
Standard
Incandescent
Standard
Quick
Linear
Red Shift
N/A
Disabled
Disabled
Disabled
N/A
White Point
N/A
3200
3200
5600
N/A
Local Settings
Status
Indicators
On
On
On
On
On
Overtemp
Dark
Dark
Visible
Dark
Visible
