Chapter 3: Installation
This chapter describes the installation of the Tambourine 100 power supply.
1.9. Site Requirements
You can guarantee the safe operation of the Tambourine 100 by ensuring that it is installed in
an appropriate environment.
Feature Value
Ambient operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Maximum non-condensing humidity 90%
Operating area atmosphere
No flammable gases or vapors permitted in area
Models for extended environmental conditions are available.
Caution :
The Tambourine 100 dissipates its heat by driven fan convection. The maximum ambient
operating temperature of 0 °C to 40 °C (32 °F to 104 °F) must not be exceeded.
Make sure that no cover closes the grids at both ends of the power supply.
1.10. Hardware Requirements
1.1.1.1. AC Input Requirements
Circuit Breakers & Contacts Three-Phase Supply Voltage
Circuit breaker current rating 80 A Type C
Circuit breaker voltage rating 250 VAC / 480 VAC depending upon operating AC
voltage
Contactor 80 A
1.1.1.2. Recommended Wire Cross-Sections (All Models)
Feature Connection Details
High Current
(large conn.)
Medium current
(small conn.)
AC input
AC1, AC2, AC3 18 to 6 AWG
24 to 14 AWG
DC Output
VP+, VN-
18 to 6 AWG 24 to 14 AWG
Protective earth
PE
18 to 6 AWG 24 to 14 AWG
