Tambourine 100 Power Supply
MAN-TAM-100IG (Ver. 1.101)
10
1.8.2.
Electrical and Mechanical Specifications
Power Supply
TAM-100/120VAC
TAM-100/230VAC
TAM-100/480VAC
Nominal
Input AC Voltage
3X120VAC
3X230VAC
3X480VAC
Max
Input AC Voltage
3X125VAC
3X270VAC
3X528VAC
Max Output Power Cont.
18KW
38KW
75KW
Max Output Power Peak
36KW
76KW
150KW
Nominal DC bus Output
(at nominal AC Voltage)
170 VDC
325 VDC
560VDC for 400VAC input
680VDC for 480VAC input
Shunt Power (Peak)
9KW
11KW
23KW
Shunt trip voltage (V)
182 to 189
382 to 386
747 to 758
DC Output Cont. Current
100A
100A
100A
DC Output Peak Current
200A
200A
200A
Mating Drives
XXX-YYY/200
XXX-YYY/400
XXX-YYY/800
Aux Power supply Voltage &
power
20VDC to 27.5VDC
12W (including fan)
20VDC to 27.5VDC
12W (including fan)
20VDC to 27.5VDC
12W (including fan)
Weight
5Kg
5Kg
5Kg
Operating temperature
0˚C to 40˚C
0˚C to 40˚C
0˚C to 40˚C
Table 2: Tambourine 100 Electrical and Mechanical Specifications
1.8.3.
Shunt Regulator
A shunt regulator is included in the power supply section of the Tambourine 100. The shunt
regulator is a switching type, wherein dissipative elements (power resistors) are switched
across the DC bus, whenever the voltage reaches a predetermined level. The function of the
shunt regulator is to regulate the voltage of the DC bus during the period of motor
deceleration, when there is a net energy outflow from the motor to the servo drive, to prevent
the servo drive from disabling itself as a result of an “over-voltage" type reason.
When the capacitors charge-up reaches the predetermined shunt threshold level, the shunt
regulator begins its regulating action. The bus is regulated to the specific model type voltage,
until the regeneration-energy is dissipated.
